ASTM Publishes New Standard for Beach Umbrellas and Anchor Devices

Loading component...

SafeGuardSHardgoodsMay 06, 2024

Loading component...

SG 65/24

ASTM has published a new consumer safety specification for beach umbrellas and anchor devices, designated ASTM F3681-24.

In April 2024, ASTM International published a new standard consumer safety specification for beach umbrellas and anchor devices with designation ASTM F3681-24. The standard addresses the hazards identified by the U.S. Consumer Product Safety Commission (CPSC), which includes lacerations and impalement from the shaft/pole of a windblown airborne beach umbrella.

The standard defines beach umbrella and anchor device as follows:

Beach umbrella – a removable device installed in or on the sand on a beach, consisting of a canopy supported by a single shaft/pole, used as protection against sun, rain or other potential weather
Anchor device – a device that is attached to or integrated into the umbrella pole and is secured in or on the sand on a beach, which enables the umbrella to perform in an open upright or angled position and prevents the umbrella from becoming airborne

Requirements in the standard includes:

Attachment strength

Beach umbrella/anchor systems with an area of the umbrella plane 45 ft2 or less may use either the mechanical pull or wind tunnel test method
Beach umbrella/anchor systems with an area of the umbrella plane over 45 ft2 must use the wind tunnel test method
The mechanical pull test method is performed by installing the umbrella (or bottom pole) with anchor system tilted at 20° angle into or on the sand box. A 75 lbf pull force is applied to the top of the umbrella (or bottom pole) within five seconds and held for 20 seconds. This test simulates the upward lift force created by a 30-mph wind

Marking and labeling

Requires warning label shown below to be on the product and packaging (if the on-product label is not visible through the retail package in its entirety).

Loading component...

Loading component...

Requires compliance label shown below for anchor devices as applicable.

Loading component...

Instructional literature

Requires the providing of instructions that include information on assembly, installation, operation, warnings, and maintenance (where applicable). A replica of the warning label is also required to be on the instructions

The standard was developed by the ASTM Market Umbrellas Subcommittee (F15.79) and approved on April 1, 2024.

Copy of the standard can be purchased at ASTM International
